Personal winch "S-Class" 22 m.

The new generation of SWI-TEC products!

Personal winch "S-Class" with Dyneema rope.

Safe personal lifting with multiple application possibilities.

The Personal winch "S-Class" includes a number of features that make it an absolutely reliable accessory.

The SWI-TEC S-Class corresponds to the basic "Classic" model, but features additional modifications such as a mandatory sliding cable guide and a cable drum with special grooves.

The S-Class personal lifting winch has been tested and approved according to the latest European standards (EN 1808, Personal lifting systems at height) and according to the German standard BGR 159 (Safety regulation regarding personal lifting systems) and is approved for facade work.
According to these regulations, it is still mandatory to insure against the risk of falling by using an additional safety system.

• Reduction 1 : 10
• Premium materials and solid construction
• Available in two models, up to 13.00 m or up to 22.00 m in height
• In production for over 15 years
• Small footprint (a sturdy bag is available as an option)
• It can be operated by the operator but also by a third person on the ground
• The lifting line is made of Dyneema with very high breaking load.
• The guide drum of the manoeuvring line works on rollers and is protected from any water splashes.

Possibilities of use:

• Repair or cleaning interventions on the facade
• Access to silos or composting pits
• Rescue of people
• Mountain interventions, tree maintenance, etc.
• Interventions on roofs or coverings
• The guide drum of the manoeuvring line works on rollers and is protected from any water splashes.

Important: The anchoring point of the lifting winch must be able to hold a maximum load of 750.00 kg, as prescribed by the German regulation BGR 159

• EN ISO 12100:2011-03: Safety of machinery - General principles for design - Risk assessment and risk reduction.
• EN 1808: 1999 + A1, 2010: Safety requirements for the design of suspended access equipment, stability criteria, construction, testing
• BGR 159: Suspension access equipment


Technical features:
